Product information

This LF Reader enables SEMI-compatible communication (SECS-II via HSMS) with tools or MES systems through its RJ45 Ethernet port. Setup and testing are simple thanks to browser-based access to the integrated web server.

The internal RFID transceiver complies with the TIRIS standard and supports both reading and writing of conventional LF transponders. Sensor integration allows automatic RFID read triggering without host intervention.

This makes it an ideal multiplex solution for production equipment with up to four identification positions, such as loadports, and is particularly well-suited for retrofitting existing semiconductor tools or integrating into new
multi-loadport systems

Key Features

  • 4 Antenna connections
  • Supports up to 4 NPN, PNP or Push Pull sensors with standard M8 connectors
  • SECS-II support
  • Integrated webserver for setup & test

Benefits

  • Lower investment
  • Reduced cabling effort
  • Minimal mounting effort
  • Efficient retrofit
  • Automatic reading without host intervention
  • Standardized interfaces and components
